Briton 1130B Fire Rated Door Closer, Adjustable EN1-EN6 in Silver
1 1

Briton 1120B Fire Rated Door Closer, Adjustable EN1-EN6

$244.94
$244.94 $244.94
Save 0
Sold out
Tax included.
  • SKU:
    DCDA1130B.SV
  • Vendor:
    Briton

Briton 1120B Fire Rated Door Closer, Adjustable EN1-EN6

The Briton 1130 Series is a non-handed, slimline unit designed to be used on commercial interior/exterior wooden and metal doors e.g. storeroom, office and toilet doors.

The closer is an adjustable 1-6 strength closer to suit the most popular range of door sizes.

Door closing is hydraulically controlled, with adjustable back check and regulators to give the desired closing speed. The 1130 has a precision rack and pinion mechanism, and is easily mounted to the surface of door or the top jamb.

Variable Closing Force: EN1-EN6 Arm

Fire rated

Specifications:

  • Universal, fully reversible, non-handed door closer.
  • Closer body constructed from pressure die cast aluminium with steel rack and pinion.
  • Tested to 500,000 cycles.
  • Fully adjustable 1-6 strength slide arm.
  • Factory set to strength 3.
  • Independent adjustment valves for controlling backcheck, closing and latching speeds.
  • Fire rated.
  • Finished in matt black.
  • Maximum Door Leaf Width: 850mm to 1400mm
  • 40-120kg door weight
  • Adjustment Controls: Closing Speed, Latching Speed, Backcheck
  • Finish: Silver

    • Delivery Time:

    Downloads:

    Technical Brochure
